Application
Tensioned Cu, Cu-Steel, steel or Bz cables
Characteristics
Service load min. 3 kN / max. 25 kN
Breaking load of corpus min. 80 kN
Material
Corpus stainless steel / Collet AlBz
Legend
1) With colour code
| Article No. |
|
|
Catenary wire section
|
|
|
|
|
||
|---|---|---|---|---|---|---|---|---|---|
|
610.019.106 | S150 | 15.8 | 150 | 1.41 | ||||
|
|
610.063.000 | S161 | 16.8 | 161 | 1.41 | ||||
|
|
610.072.000 | S185 | 17.5 | 185 | 1.41 | ||||
|
|
610.061.000 | S202 | 18.8 | 202 | 1.41 | ||||
|
|
610.069.000 | S202 | 18.8 | 202 | 1.41 | 1 | |||
|
|
610.021.173 | S240-250 | 21 | 240 - 250 | 1.41 | ||||
|
|
610.073.000 | S161 | 16.8 | 161 | 1.41 | 1 | |||
|
|
610.079.000 | FD193 | 16.8 | 193 | 1.41 | 1 | |||
|
|
610.082.000 | S185 | 17.5 | 185 | 1.41 | 1 |
